Introduction
95 zirconia beads formed by dripping method are the high-end grinding product, because of the forming method and raw material, they have more advantages. Using high-purity zirconia powder, prepared by hydrothermal method, as raw material, and formed by dripping production process. Compared with traditional forming processes (rolling, extrusion, etc.), they have fewer porosity, higher wear resistance and narrow particle size distribution, making them the best choice for the high-end materials grinding.
Product Features
High Wear Resistance: Titration zirconia beads have outstanding wear resistance, suitable for long-term continuous operation.
High Energy Transfer Efficiency: High density and high hardness combination provide high energy transfer efficiency and significant grinding effect.
Low Contamination: Chemically stable, causing no contamination to grinding materials.
Product Parameters:
|
Models |
SAb-003 |
SAb-005 |
SAb-010 |
SAb-020 |
SAb-023 |
SAb-028 |
SAb-030 |
SAb-035 |
SAb-045 | SAb-055 | SAb-065 |
|
Size(mm) |
0.03 |
0.05 |
0.10 |
0.20 |
0.23 |
0.28 |
0.30 |
0.35 |
0.45 | 0.55 | 0.65 |
|
Tolerance(mm) |
0.028-0.038 |
0.04-0.06 |
0.08-0.12 |
0.18-0.22 |
0.20-0.25 |
0.25-0.30 |
0.28-0.32 |
0.32-0.38 |
0.40-0.49 | 0.50-0.59 | 0.6-0.7 |
|
True density(g/cm3) |
6.05 |
6.05 |
6.05 |
6.05 |
6.05 |
6.05 |
6.05 |
6.05 |
6.05 | 6.05 | 6.05 |
|
Bulk density(g/cm3) |
3.60 |
3.70 |
3.60 |
3.63 |
3.65 |
3.70 |
3.70 |
3.70 |
3.70 | 3.70 | 3.70 |
|
Vickers hardness (HV) |
≥1350 |
≥1350 |
≥1350 |
≥1350 |
≥1350 |
≥1350 |
≥1350 | ≥1350 | ≥1350 | ≥1350 | ≥1350 |
|
Crushing strength(N) |
- |
- |
≥10 |
≥40 |
≥100 |
≥140 |
≥300 |
≥500 |
≥800 | ≥800 | ≥800 |
|
Self-consumption(%) |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 |
≤0.01 | ≤0.01 | ≤0.01 |
Product size can be customized.
Appearance
- Color: White or ivory white
- Shape: Spherical
- Surface Finish: Smooth without cracks
Applications
- New Energy Batteries: 95 zirconia beads formed by dripping method are very suitable for the ultra-fine grinding of battery materials, to increase energy density, charge-discharge efficiency and other main performance.
- Pharmaceutical Industry: Used for clean grinding and uniform mixing of drugs, ensuring effectiveness and consistency.
- High-end Ceramic Ink Industry: Get Nano-grade particle size without contamination.
